Art.Nr. 26274677
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
| Item no. | DescriptionArticle no. |
|---|
| 1 | shower arm93768670 |
| 2 | hollow set screw M5x598446000 |
| 3 | filter packing94246000 |
| 4 | head shower26271677 |
| 5 | tile-matching-disk 7 mm93813670 |
| 6 | pipe 945 mm93770670 |
| 7 | pipe 845 mm93906670 |
| 8 | pipe 1145 mm93907670 |
| 9 | support, assy93729670 |
| 10 | O-ring 12x298214000 |
| 11 | O-ring 11x298127000 |
| 12 | handshower26270677 |
| 13 | back flow preventor cartridge93339000 |
| 14 | shower hose Isiflex'B 1,60 m28276670 |
| 15 | aerator M24x1 (38 l/min)92513000 |
| 16 | diverter knob93766670 |
| 17 | selector97978000 |
| 18 | handle for thermostat93727670 |
| 19 | nut98913000 |
| 21 | cartridge for exchanged connections92373000 |
| 22 | handle93731670 |
| 23 | shut off unit with selector98283000 |
| 24 | connecting thread G½93730670 |
| 25 | non return valve (pressure-resistant up to 2 MPa)93136000 |
| 26 | non return valve96737000 |
| 27 | O-ring 16x298133000 |
| 28 | filter packing96922000 |
| 29 | escutcheon Ø 70 mm93718670 |
| 30 | set of S-unions94140007 |
